White&Warm White&Amber Color Addressable LED Tape - Full Color LED Strip - Products

Full Color LED Strip

White&Warm White&Amber Color Addressable LED Tape

Application:

1. Hotels,restaurants,nights clubs,

2. Shopping malls,various shops,

3. Coffee/wine bars, furniture light

4. Cinemas,beauty centers,
5. Coffee/wine bars, furniture light.

Share to

White&Warm White&Amber Color Addressable LED Tape

Product Parameter:

P/N	LED Quantity	Pixel pitch	Voltage(V）	Power(W/m)	IC	Color Temperature	Waterproof
S606812WWY	60leds/M	P16mm	DC5V	14.4W	SK6812	W:6000-7000k/ ww:2800-3200k/ Amber:1800-2000k	IP20/IP65

Features:

1. Top SMD internal integrated high quality external control line serial cascade constant current IC,

2. Control circuit and the chip in SMD 5050 components, to form a complete control of pixel, color mixing uniformity and consistency,

3. Built-in data shaping circuit,

4. Gray level adjusting circuit (256 level gray scale adjustable),

5. Using a typical data transmission frequency of 800 Kbps, when the refresh rate of 30 frames , per second,

6. The transmission distance between two points over 10M,

7. 5meter per roll,Cut-able of each single LED/Pixe.

Conncetion:

White&Warm White&Amber Color Addressable LED Tape Video:
