iPixel LED Light Co.,Ltd
Make the world colorful
Make the world colorful
Application:
1. Business premises, stage, conference room,
2. Display lights, ancient buildings,
3. Stage illumination,
4. Viaduct overpass, building exterior wall, building landmark,
5. Landscape building, outdoor plaza,
6. Color of landscape, wall and display,
F125 RGB Series
Product Parameter:
Product Number
F125 RGB Series
Power
48W
Quantity of LED
48PCS
Operating Voltage
DC24V
Control (IC)
DMX512 3CH
Light Source
TX-3535 3in1
Size (mm)
L 440 * W 125 * H 185
Beam Angle
12°、24°、36°
Lumens
R: 248lm G: 584lm B: 180lm
Glass Thickness
4mm
IP Level
IP65
Life Time
50,000 Hours at Ta=40°C
Work Temp
-20℃ - 50℃
Operating Humidity
10%~95%RH
Finishing Materials
Aluminum and Tempered Glass
Features:
- using brand high-power LED chips, and a unique array of LED layout design, with high thermal conductivity, low light decay, pure color, no ghosting.
- The shell is extruded from 6063 aluminum extrusion with high thermal conductivity and is resistant to high-strength impact. The surface of the lamp is treated with electrostatic spray, which is corrosion resistant and UV resistance.
- Transparent parts are made of high-strength toughened glass with 99% light transmittance, high light transmittance and impact resistance.
- long life and low light decay, the light effect can still maintain nore than 80% after 30,000 hours.
- Customized design such as monochrome, high voltage, color mixing, multi-effect, multi-power, lengthening, etc according to customer require ments.
- Widely used in: outdoor sports venues, park squares, architectural lighting projects.
Structural hint:
