Application:
1. LED strip,led light bar.
2. LED tube,led pixel light.
3. Light source,led screen.
4. LED module,Other Electronics.
Product Parameters：
|
MODEL |
LPV-60-5 |
LPV-60-12 |
|
|
OUTPUT |
DC VOLTAGE |
5V |
12V |
|
RATED CURRENT |
8A |
4A |
|
|
CURRENT RANGE |
0~8A |
0~4A |
|
|
RATED POWER |
40W |
60W |
|
|
RIPPLE&NOISE(max.) Note.2 |
80mVp-p |
120mVp-p |
|
|
VOLTAGE TOLERANCE Note.3 |
±8.0% |
±5.0% |
|
|
LINE REGULATION |
±1.0% |
||
|
LOAD REGULATION |
±6.0% |
±2.0% |
|
|
SETUP,RISE TIME Note.6 |
500ms, 20ms / 230VAC 5 at full load ; 00ms, 20ms / 115VAC (for 5~36V) 500ms, 30ms / 230VAC 500ms, 30ms / 115VAC at full load(for 48V) |
||
|
HOLD UP TIME(Typ.) |
50ms/230VAC 14ms/115VAC at full load |
||
|
INPUT |
VOLTAGE RANGE Note.4 |
90~264VAC 127-370VDC |
|
|
FREQUENCY RANGE |
47~63Hz |
||
|
EFFICINCY(Typ.) |
76% |
83% |
|
|
AC CURRENT |
1.2A/115VAC 1A/230VAC |
||
|
INRUSH CURRENT(Typ.) |
COLD START 60A(twidth=525us measured at 50% lpeak)at 230VAC |
||
|
LEAKAGE CURRENT |
0.25mA/240VAC |
||
|
PROTECTION |
OVER CURRENT |
110~150% rated output power |
|
|
Protection type:Hiccup mode,recovers automatically after fault condition is removed |
|||
|
OVER VOLTAGE |
5.75~6.75V |
13.8~16.2V |
|
|
Protection type:Shut down o/p voltage,re-power onto recover |
|||
Features :
1. Constant voltage design
2. Universal AC input / Full range
3. Withstand 300VAC surge input for 5 seconds
4. Protections: Short circuit / Overload / Over voltage
5. Cooling by free air convection
6. Fully encapsulated with IP67 level(Note.8)
7. Fully isolated plastic case
8. Class power unit, no FG
9. Pass LPS
10. Suitable for LED lighting and moving sign applications(Note.7)
11. 100% full load burn-in test
12. Low cost, high reliability
13. 2 years warranty
