Application:
1. LED strip,led light bar.
2. LED tube,led pixel light.
3. Light source,led screen.
4. LED module,Other Electronics.
Product Parameters：
|
MODEL |
NES-350-5 |
NES-350-12 |
|
|
OUTPUT |
DC VOLTAGE |
5V |
12V |
|
RATED CURRENT |
60A |
29A |
|
|
CURRENT RANGE |
0~60A |
0~29A |
|
|
RATED POWER |
300W |
348W |
|
|
RIPPLE&NOISE(max.) Note.2 |
150mVp-p |
150mVp-p |
|
|
VOLTAGE ADJ.RANGE |
4.5~5.6V |
10~13.5V |
|
|
VOLTAGE TOLERANCE Note.3 |
±3.0% |
±1.5% |
|
|
LINE REGULATION |
±0.5% |
±0.5% |
|
|
LOAD REGULATION |
±2.0% |
±1.0% |
|
|
SETUP,RISE TIME |
1000ms,50ms/230VAC 1000ms,50ms/115VAC at full load |
||
|
HOLD UP TIME |
20ms/230VAC 16ms/115VAC at full load |
||
|
INPUT |
VOLTAGE RANGE Note.4 |
90~132VAC/180~264VAC by switch 254-370VDC |
|
|
FREQUENCY RANGE |
47~63Hz |
||
|
EFFICINCY(Typ.) |
78% |
83% |
|
|
AC CURRENT |
7A/115VAC 4A/230VAC |
||
|
INRUSH CURRENT(max.) |
40A/115VAC 60A/230VAC |
||
|
LEAKAGE CURRENT |
<3.5mA/240VAC |
||
|
PROTECTION |
OVER LOAD |
105~135% rated output power |
|
|
Protection type:Constant current limiting,recovers automatically after fault condition is removed |
|||
|
OVER VOLTAGE |
5.75~7.5V |
13.8~16.2V |
|
|
Protection type:Shut down o/p voltage,re-power onto recover |
|||
|
OVER TEMPERATURE |
90℃±5℃ |
85℃±5℃ |
|
|
Protection type:Shut down o/p voltage,recovers automatically after temperature goes down |
|||
|
|
|
|
|
|
|
|
||
Features:
1. AC input range selectable by switch
2. Protections: Short circuit/Overload/Over voltage/Over temperature
3. Forced air cooling by built-in DC fan
4. Withstand 300vac surge input for 5 second
5. Built-in constant Fan ON-OFF control
6. Built-in constant current limiting circuit
7. 100% full load burn-in test
8. LED indicator for power on
9. Fixed switching frequency at 90KHz
10. Low cost,high reliability
11. 2 years warranty
