Application:
1. LED strip,led light bar.
2. LED tube,led pixel light.
3. Light source,led screen.
4. LED module,Other Electronics.
Product Parameters：
|
RS-15-5
|
OUTPUT |
DC Voltage | Rated Current | Rated Power | Ripple & Noise (max.) Note.2 | Load Regulation |
| 5V | 3A | 15W | 80mVp-p | ±0.5% | ||
|
INPUT |
Voltage Range | Frequency Range | Leakage Current | Overload | ||
|
85-264VAC 120-370VDC |
47 ~ 63Hz | <2mA / 240VAC | Above 105% rated output power | |||
1. Universal AC input /Full range.
2. Protections:Short circuit/Overload/Over voltage/Over remperature.
3. Cooling by free air convection.
4. LED indicator for power on.
5. 100% full load burn-in test.
6. No load power consumption<0.5W.
7. All using 105℃ long life electrolytic capacitors.
8. Withstand 300VAC surge input for 5 second .
9. High operating temperature up to 70℃.
10. Withsstand 5G vobration test.
11. High efficiency,long life and high reliability.
12. 3 years warranty.
